Our Product
X10 IoT Network as a Service (NaaS)
X10 IoT Network-as-a-Service (NaaS) solution is an end-to-end fully integrated network using our next generation compact electronically steered antenna (X10 IoT Terminals), designed to scale for everything from IoT to near real-time network requirements.
Through the application of phased array technology, the terminal can quickly track and switch between multiple orbits such as GEO, MEO and LEO. With built-in modem and key RF components, the compact X10 IoT terminals allows easy deployment for mission and business critical requirement in various field such as emergency rescue, logistics, power grid, public security, national defence, scientific research, oil fields, agriculture, animal husbandry and many others.
Terminal Features
High speed tracking
Compact terminal fitted with built-in modems and tracking module
Advanced electronic steering technology which allows rapid switching and tracking of satellites across GEO, MEO and LEO orbits
Free from complex installation, cabling, connection and commissioning
Flexible and scalable for wide scenarios of applications
Applications
Emergency Service
Logistics
Public Security
National Defence
Scientific Research
Agriculture
Animal Husbandry
Mining
Terminal Specifications
Overall Specifications | |||
Model No. |
IoT-Ku128 |
IoT-Ku256 |
IoT-Ka256 |
Antenna Type |
Electronic Steering Phased Array | ||
RF Performance | |||
Frequency Range |
TX 13.75~14.50 GHz, RX 10.70~12.75 GHz |
TX 27.5~31.0 GHz, RX 17.7~21.2 GHz | |
EIRP |
≥ 23.0 dBW @ 90°EL |
≥ 29.0 dBW @ 90°EL |
≥ 30.0 dBW @ 90°EL |
≥ 19.5 dBW @ 30°EL |
≥ 24.5 dBW @ 30°EL |
≥ 25.5 dBW @ 30°EL | |
G/T |
≥ 1.0 dB/K @ 90°EL |
≥ 3.5 dB/K @ 90°EL |
≥ 0.0 dB/K @ 90°EL |
≥ -3.5 dB/K @ 30°EL |
≥ -1.0 dB/K @ 30°EL |
≥ -4.5 dB/K @ 30°EL | |
Polarization |
Linear & Circular, automatic switching |
Circular | |
X-Pol Isolation |
>30dB@ 90°EL | ||
Coverage |
0-360° @ azimuth, Elevation angle 30° to 90° | ||
Integrated Tracking System | |||
Integrated Tracking Type |
<DVB-S, DVB-S2, DVB-S2X | ||
Beam Switching Time |
≤3ms (any position) | ||
Scan Mode |
Electronic Steering + 2D | ||
Modem | |||
Internal /External Modem |
Built-in Extend Networks Modem (default) / External modem supported | ||
Mechanical | |||
Dimensions |
≤325×230×52mm |
≤475×285×61mm |
≤275×189×43mm |
Weight |
≤2.8kg |
≤6.5kg |
≤3kg |
Environmental | |||
Operating Temperature |
-25°C ~ +55°C (Standard), | ||
-40 °C ~ +70 °C (Customizable) | |||
Ingress Protection |
IP66 | ||
Power | |||
DC Power Supply |
(With Adapter) AC 90 ~ 264V/50~60Hz | ||
(Without Adapter) 28VDC±5% | |||
Interfaces | |||
IF TX/IF RX |
SMA | ||
Power and Network Interface |
Waterproof Quick Plug | ||
For further information, please contact us at enquiry@extendnetworks.sg.
